Smart Household Sensor Solutions

Smart Room

Air quality sensor - PM2.5, CO2, HCHO, VOC, O3, Temp. & Humi.

To create a safe and comfortable air environment

Image	Model	Title	Detection Target	Working Principle	Output signal
	ZPH04	Particles Sensor	PM2.5	IR	UART / PWM
	ZH07	Laser dust sensor	PM1.0, PM2.5, PM10	Laser	UART / PWM
	ZH10-F	Compact Laser Dust Sensor Module	PM1.0,PM2.5,PM10	Laser	UART / PWM
	MH-Z1911A	CO2 Module	CO2(Carbon dioxide)	NDIR	UART / PWM
	PAS CO2	CO2 Module	Carbon Dioxide CO2	PAS	Serial Port (UART)
	ZE08K-CH2O	HCHO Formaldehyde Sensor	CH2O, HCHO, Formaldehyde	Electrochemical	DAC / UART / PWM
	ZPS20	Digital Sensor Module	Formaldehyde, benzene, VOC, Temperature, Relative humidity	Semiconductor, Module	I2C
	ZE25-O3	Ozone Detection Module	O3	Electrochemical，Module	DAC / UART / PWM
	ZPHS01C	Multi-in-One Sensor Module	PM2.5, CO2, CH2O, TVOC, Temperature&Humidity	Module	UART
	ZP07	Air-Quality Detection Module	Formaldehyde, benzene, carbon monoxide, hydrogen, alcohol, ammonia, smoke of cigarette	Module，semiconductor	TTL level

PIR sensor - human induction, anti-intrusion

Automatic control of lighting, door, and security monitoring

Image	Model	Title	Target	Working Principle	Size	Receiving wave length
	RD-624	PIR Pyroelectric Infrared Sensor	Human body induction	Pyroelectric effect	TO-5 9.1x4.5mm	5-14um
	RD-626W	PIR Pyroelectric Infrared Sensor	Human body induction	Pyroelectric effect	TO-5 9.1x4.5mm	5-14um
	RDB226S	Digital PIR Pyroelectric Infrared Sensor	Human body induction	Pyroelectric effect	TO-5 9.1x4.5mm	5-14um
	ZRD-09	PIR Motion Sensor Module	Induction signal	Pyroelectric effect	32mm*24mm*24mm	5-14um

Refrigerant sensor - Refrigerant

Refrigerant leakage detection and alarm of air conditioner, HVAC, heat pump, refrigerator

Image	Model	Title	Target	Working Principle	Output signal
	MH-Z1542B-R32	Refrigerant Sensor Module	Refrigerant	Non-dispersive infrared (NDIR)	UART
	ZRT510	Refrigerant Sensor Module	R454B, R32, R290, Refrigerant	Non-dispersive infrared (NDIR)	UART/PWM
	MP510C	Refrigerant Gas Sensor	Refrigerant gases：R32、R134a、R410a、R290	Semiconductor	/
	ZP201	Refrigerant gas detection module	Refrigerant gas R32	Module, Semiconductor	TTL level
	ZP211	Refrigerant gas detection module	Refrigerant gas R290	Module, Semiconductor	PWM

Dirt sensor - Dirt, dust

Intelligent detection of dirt in vacuum cleaner, sweeping robot

Image	Model	Title	Target	Working Principle	Output signal
	ZPH05	Micro-dust Sensor	Micro-dust	Pptical contrast	UART/PWM

Smart Kitchen Application

The smart kitchen allows products to have the ability to “think” and at the sametime to be linked with other products to bring a better user experience, such as smart refrigerators, smart dishwashers, and various smart kitchen appliances. They will intelligently help us to plan a day's kitchen schedule, making food safer, life easier, and enable us to spare more time on favorite things.

Gas sensor-CH4, C3H8, smoke, CO, burnt smell, odor

Gas leakage detection, smart alarm and control of gas pipeline, stove, rangehood, gas heater...)

Image	Model	Title	Target	Working Principle	Output signal
	ZP14	Combustible Gas Detection Sensor Module	Natural gas,CH4	Module，Semiconductor	/
	ZC13	Methane CH4 Sensor Modul	methane CH4, natural gas, flammable gas	Module，Catalytic	UART
	ZP13	Smoke Sensor Module	C3H8、smoke	Module，Semiconductor	TTL level
	ZE15-CO	Electrochemical Carbon Monoxide Gas Sensor Module	CO	Module, Electrochemical	UART
	ZE33	Water Heater Gas Leakage and Incomplete Combustion Detection Module	CO, CH4	Module, Electrochemical	PWM
	ZP101	Burnt Smell Detection Module	Food burnt gas	Semiconductor	/
	GM-802B	MEMS NH3 Gas Sensor	NH3	Semiconductor、MEMS	/
	ZP07	Air-Quality Detection Module	Formaldehyde, benzene, carbon monoxide, hydrogen, alcohol, ammonia, smoke of cigarette, essence &etc.	Module，Semiconductor	TTL level
	MP503	Air-Quality Gas Sensor	C2H5OH、smoke、iso-butane、CH2O	Semiconductor	/

Temperature sensor-temperature, Anti-dry burnt

Temperature monitoring of stove, oven, frying machine, air fryer; preventing dry burnt

Image	Model	Title	Target	Working Principle	Output signal
	MRTD-3011	Digital Thermopile Temperature Sensor	Temperature	Seebeck	/
	MRT-313	Thermopile Temperature Sensor	Temperature	Seebeck	/
	ZMT500-A	Non-contact anti-dry probe		Infrared temperature measurement	Analog

Temperature&Humidity sensor - temperature&relative humidity

To preserve fresh food and temperature detection

Image	Model	Title	Target	Working Principle	Output signal
	ZS13A	Temperature and Humidity Sensor Module	Temperature and Humidity	Semiconductor, Module	/

Pressure sensor-Gauge Pressure/Absolute Pressure/Sealed Gauge

Measure pressure of gas, water pipeline, coffee maker...

Image	Model	Title	Detection principle	Response time
	WPAK63	General Type Isolation-Film Pressure Sensor	Diffused Silicon	≤1ms
	WPCK89	Digital Output Pressure Transmitter	/	≤1ms

Smart Bathroom

Combining sensors of human induction, temperature, relative humidity, pressure and flow with the electronic control, digital, and automation as to realize expanded function of bathroom products, and improve the experience of health, comfort and convenience.

Temperature&Humidity sensor - temperature&relative humidity

Detection of temperature&relative humidity for a comfortable space

Image	Model	Title	Target	Working Principle	Output signal
	ZS13A	Temperature and Humidity Sensor Module	Temperature and Humidity	Semiconductor, Module	/

Odor sensor-odor

Detection of odor smell and automatic linkage to ventilation for fresh air

Image	Model	Title	Target	Working Principle	Output signal
	GM-802B	MEMS NH3 Gas Sensor	NH3	Semiconductor、MEMS	/
	ZP07	Air-Quality Detection Module	Formaldehyde, benzene, carbon monoxide, hydrogen, alcohol, ammonia, smoke of cigarette, essence &etc.	Module，Semiconductor	TTL level
	MP503	Air-Quality Gas Sensor	C2H5OH、smoke、iso-butane、CH2O	Semiconductor	/

PIR sensor - human induction

Automatic control of lighting, flush

Image	Model	Title	Target	Working Principle	Size
	RD-624	PIR Pyroelectric Infrared Sensor	Human body induction	Pyroelectric effect	TO-5 9.1x4.5mm
	RD-626W	PIR Pyroelectric Infrared Sensor	Human body induction	Pyroelectric effect	TO-5 9.1x4.5mm
	RDB226S	Digital PIR Pyroelectric Infrared Sensor	Human body induction	Pyroelectric effect	TO-5 9.1x4.5mm
	RD-09	PIR Motion Sensor Module	Induction signal	Pyroelectric effect	32mm*24mm*24mm
