ZEH100 Multi-in-One Energy Storage Sensor Module
ZEH100 Multi-in-One Energy Storage Sensor Module
  • CO, H2, VOC, Smoke, Temperature
  • Read More
ZE610-H2 Electrochemical H2 Module
ZE610-H2 Electrochemical H2 Module
  • Hydrogen gas (H2)
  • 0~5000ppm
  • Read More
MPv-820 Hydrogen Gas Sensor
MPv-820 Hydrogen Gas Sensor
  • H2
  • 100~3000ppm
  • Read More
MEv-GH01 Hydrogen Gas Sensor
MEv-GH01 Hydrogen Gas Sensor
  • H2
  • 0~2000ppm
  • Read More
Electrochemical Carbon Monoxide Gas Sensor Module ZE730-CO
Electrochemical Carbon Monoxide Gas Sensor Module ZE730-CO
  • Carbon Monoxide Gas
  • 0~1000ppm
  • Read More
CMV-2021D Catalytic H2 Sensor
CMV-2021D Catalytic H2 Sensor
  • H2
  • 0~100 %LEL
  • Read More
RPFA913CG Pyro-electric Flame sensor
RPFA913CG Pyro-electric Flame sensor
RPFA913CF Pyro-electric Flame sensor
RPFA913CF Pyro-electric Flame sensor
RPFA913CE Pyro-electric Flame sensor
RPFA913CE Pyro-electric Flame sensor
RPFA913CD Pyro-electric Flame sensor
RPFA913CD Pyro-electric Flame sensor
RPFA913CC Pyro-electric Flame sensor
RPFA913CC Pyro-electric Flame sensor
ME2-CO-Φ14x5 Carbon Monoxide Gas Sensor
ME2-CO-Φ14x5 Carbon Monoxide Gas Sensor
  • CO
  • 0~1000ppm
  • Read More
WHT20 MEMS type Temperature and Humidity Sensor
WHT20 MEMS type Temperature and Humidity Sensor
  • Environment relative humidity,temperature
  • Read More
Battery Leak Detection Module ZE21-CS for Electric Vehicle
Battery Leak Detection Module ZE21-CS for Electric Vehicle
  • CO, H2, Battery leakage comprehensive gas
  • 0~1000ppm
  • Read More
Electrochemical Detection Module ZE03
Electrochemical Detection Module ZE03
  • CO,O2,NH3,H2S,NO2,O3,SO2, CL2,HF,H2,PH3,HCL, etc.
  • See manual
  • Read More
ZP13 Smoke Sensor Module
ZP13 Smoke Sensor Module
  • C3H8、smoke
  • Output A signal switching value output
  • Read More
MP801 Air-Quality Gas Sensor
MP801 Air-Quality Gas Sensor
  • air quality:C6H6、C7H8、CH2O、C2H5OH、smoke
  • 0.5-1000ppm(C2H5OH)
  • Read More
MP503 Air-Quality Gas Sensor
MP503 Air-Quality Gas Sensor
  • C2H5OH、smoke、iso-butane、CH2O
  • 10-1000ppm(C2H5OH)
  • Read More
MP-2 Smoke Gas Sensor
MP-2 Smoke Gas Sensor
  • C3H8、smoke
  • 200~10000ppm
  • Read More

Help you compare our sensors

Table Overview for Winsen Energy Storage

Unsure which sensor to choose, please leave your infomation or email us

Modle Detection principle Characteristics Target gas Detection range Size

ZEH100
High temperature resistance; Fast response; High precision CO, H2, VOC, Smoke, Temperature

ZE610-H2
Electrochemical High sensitivity, low power consumption, long lifespan Hydrogen gas (H2) 0~5000ppm

MPv-820
Semiconductor High sensitivity, fast response speed H2 100~3000ppm

MEv-GH01
Electrochemical Low consumption, high precision, high sensitivity H2 0~2000ppm

ZE730-CO
Electrochemical High temperature resistance, fast response, low power consumption, high precision, long life Carbon Monoxide Gas 0~1000ppm

CMV-2021D
Catalytic combustion effect The bridge output is linear,Quick response H2 0~100 %LEL

RPFA913CG
pyroelectric effect 5.0um detection band;TO-5 package, single channel, voltage mode;Low microphone effect, large FOV, high detection rate;Detection band measurement of flame signal;

RPFA913CF
pyroelectric effect 4.48um detection band;TO-5 package, single channel, voltage mode;Low microphone effect, large FOV, high detection rate;Detection band measurement of flame signal;

RPFA913CE
pyroelectric effect 4.4um detection band;TO-5 package, single channel, voltage mode;Low microphone effect, large FOV, high detection rate; Detection band measurement of flame signal;

RPFA913CD
pyroelectric effect 4.3um detection band;TO-5 package, single channel, voltage mode;Low microphone effect, large FOV, high detection rate;Detection band measurement of flame signal;

RPFA913CC
pyroelectric effect 3.8um detection band;TO-5 package, single channel, voltage mode;Low microphone effect, large FOV, high detection rate;Detection band measurement of flame signal;

ME2-CO-Φ14x5
Electrochemical Low consumption,High precision CO 0~1000ppm

WHT20
MEMS capacitive humidity sensor 1、High accuracy ±3.0% RH and ±0.5℃;2、Wide power supply voltage range, from 2.0V to 5.5V;3、SMD package suitable for reflow soldering;4、Quick response and strong anti-interference ability;5、Excellent long-term stability under high humidity condition Environment relative humidity,temperature

ZE21-CS
Module, electrochemical UART output. For battery leak detection in electric vehicle battery boxes, new energy storage and other occasions. CO, H2, Battery leakage comprehensive gas 0~1000ppm 25.43x22.33x7.3mm

ZE03
Module, electrochemical Supply UART output and analog voltage output; Use for portable and fixed gas detector, various gas detection equipment and occasion. CO,O2,NH3,H2S,NO2,O3,SO2, CL2,HF,H2,PH3,HCL, etc. See manual ø23.5mm*24.5mm

ZP13
Module,semiconductor High sensitivity,excellent long term stability, calibrated before shipment 10 seconds to 5 minutes with auto-preheating function Faulty auto-check C3H8、smoke Output A signal switching value output 24.1×20.1×15.6

MP801
Semiconductor High sensitivity to C6H6、C7H8、CH2O、C2H5OH、smoke air quality:C6H6、C7H8、CH2O、C2H5OH、smoke 0.5-1000ppm(C2H5OH) φ9.4×7

MP503
Semiconductor High sensitivity to C2H5OH、smoke、iso-butane、CH2O C2H5OH、smoke、iso-butane、CH2O 10-1000ppm(C2H5OH) φ9.4×7

MP-2
Semiconductor Good sensitivity to LPG、smoke C3H8、smoke 200~10000ppm φ9.4×7

ARE YOU LOOKING FOR SENSOR

Not sure which sensor is right?

Get a free initial consultation right now

WHAT WE DO

Energy Storage Knowledge

In the rapidly evolving landscape of energy storage, ensuring the safety and reliability of storage systems is paramount. As a leading sensor manufacturing company, we have developed a range of advanced sensors specifically tailored for the energy storage sector. Our cutting-edge sensor solutions include hydrogen detection, smoke detection, flame inspection, carbon monoxide monitoring, and temperature/humidity sensing. By integrating these sensors into energy production and storage facilities, we significantly enhance safety measures and mitigate potential risks.

Leading gas sensing Solution supplier

Our Hot Products

ANY QUESTIONS?

Frequent Asked Questions

Professional manufacturer of gas sensors, global sensing solutions provider with over 30 years of experience. Top quality guarantee, Excellent service, Customized products, Fast delivery!

Reference lead times: 1-15 days after receiving deposit depending on volume. The actual lead time can be confirmed with Winsen Order Processing Dept.

Winsen will recommend the most appropriate way of transportation (express, air, sea, train, etc.) according to customer's requirement on cost and time.

T/T, Paypal, West Union, Credit Card, etc.

MOQ is different depending on product models. Please contact Winsen sales for details.

Customer LOGO and packing design are acceptable.
Customized design and function will be provided without extra charge (including molding fee).

Sample order is acceptable and the fees will be borne by buyer.

Winsen has a complete and strict flow for offline sensors: aging-reject defective-sampling inspection-issue reports-finished ingoing...outgoing.

All Winsen products go through strict inspections and tests to make sure they are 100% qualified before shipping out.

ppm: parts per million
ppb: parts per billion
VOL: volume ratio
LEL: lower explosive limit
NDIR: Non-Dispersive Infra-Red
